Technical Specifications for Black Edition Rear Twin Shock (2014-2017):

• Collection: Black Edition
• Year: 2014-2017
• Product Group: Topline
• Shock Type: Rear Twin Shock
• Product Type: Emulsion Gas Shock
• ABE: Not specified
• Length: Adjustable from 320mm to 330mm
• Top Mount: 12x21 (MM)
• Bottom Mount: 12x21 (MM)
• Spring Dimensions: 46-25-35-200 (MM)
• Piston Size: 36mm
• Shaft Size: 12mm

Adjustment Features:

1. Thread Spring Preload:

   • Description: Fine-tune the spring by threading cylindrical shock absorbers.
   • Operation: Turn the preload and secure with a provided bolt.

2. Rebound Adjustable:

   • Description: Control shock absorber recovery speed.
   • Components: Volume control knob, needle shaft, Free Bleed oil through hole, and time adjustment dial.

3. Length Adjustable:

   • Description: Increase the length of the shock absorber.
   • Options: Upgrade by 10mm or adjustable lengths /- 5mm.

Explore superior tuning and adaptability with the Black Edition Rear Twin Shock (2014-2017), offering adjustable features for precise control and customization according to your driving preferences.
